Arduino Sketches and Libraries
(19 sketches)
| A | ||
| ATEMTallyLightRadio | Tally Light control using RFM69 data radios and AdaFruit RadioFeathers | |
| C | ||
| Christmas2013 |  |
Pixel Strips, water sensor, Ultrasonic ranging and a Christmas Tree |
| Christmas2014 | Example sketch for driving Adafruit WS2801 pixels! | |
| cpNode | cpNode CMRINet Node implementation | |
| E | ||
| ExampleDirectionOfTravel-IR | Look at the state of 2 sensors, and the order of activation sets the direction of travel. | |
| ExampleSignalStateMachine | Simulate a progression of signal aspects and a grade crossing | |
| G | ||
| GradeCrossing | Arduino Grade Crossing Controller | |
| I | ||
| IO4_IR_Detector_Active | description not provided | |
| IRDetector-Gbunza | Quad IR detector with hysteresis for IO4-IR-Detector-GBunza board on SPCoast.com | |
| J | ||
| JohnsOfficePimp | An addressible WS2801 style RGB LED string fading slowly across the HSB color space - under my desk | |
| L | ||
| LoconetControlPanel | Example of buttons throwing turnouts and LEDs echoing position | |
| LoconetLayoutControlPanel | LocoNet Layout Commander - Track power, E-STOP and slot clearing | |
| M | ||
| MRCS_cpNode_kernel | MRCS cpNode CMRI Kernel sketch | |
| O | ||
| OBS-buttons | Keyboard "emulator" for OBS Scene control | |
| OBS-buttons-2 | Keyboard "emulator" for OBS Scene control - take 2 | |
| P | ||
| PCRdemo2015 |  |
Demo code for PRC1025 demo board |
| R | ||
| RealSignalControl | Drive a LED signal head using relays or a Seeed Studio high current RGB strip driver with an external power supply. | |
| S | ||
| servotiger4x20LCD | Make music with servos and a Tiger Xylopiano - uses several servos with wooden hammers | |
| X | ||
| XBar-Wemos-nowifi | Test harness code for I2C extender | |
